Case Studies

Customization aluminum heat sink case

Product LFM(load port reader - Multiprotocol) NameN/A
TechnologyCNC metal, Extrusion IndustryTechnology
MaterialAI 5052, Aluminium 6061 LocationGermany
FinishAnodization (Natural and Black color)
Timeline50 Days
Quantity4,000 sets
Name N/A Industry Technology Location Germany

Our customer, a technology company specializing in industry, buildings, energy, and the environment, collaborated with Protolis on this project involving the production of 4000 LFM (load port reader – multiprotocol) metal enclosure.

This intricate fabrication and assembly process included extrusion for the external casing, CNC machining for precise shaping of aluminum components, and anodization for a black finish on profiles.

About our client

Model of Sustainable City

Our customer is a technology company, with a focus on industry, buildings, energy, and the environment. They customize automation
 and IT solutions.

Technical challenges and solutions

Technical and aesthetic integration: The project seamlessly integrates technical functionality with aesthetic considerations.

Critical tolerances: Maintaining precise tolerances is crucial to ensuring tight assembly with the customer’s light guide plastic parts.

Material considerations: Utilization of different aluminum alloys (6061 and 5052) based on customer requirements.

Post-anodization dimensions: Anticipating and controlling important dimensions post-anodization to ensure alignment within tolerance ranges.

Surface aesthetics: Meeting strict aesthetic requirements, including invisible rack marks after anodization.

Bracket for IFM Device
Front Panel of IFM Device

Results

By navigating through various manufacturing processes, the team ensured the production of 4000 customized load port readers that met stringent quality and aesthetic standards.

Black IFM Device with Connectors
Compact Black IFM Device
